The F3040 LED Point Light offers precise pixel-level control with IP66-rated durability, supporting DMX512 protocols. This product from a top led light manufacturer is ideal for dynamic outdoor lighting and architectural facades as a reliable led light solution.
Performance parameter:| Color | RGBW |
| LED | 4pcs SMD3535 + 2pcs SMD2835 |
| Control Method | DMX512 |
| Model No. | F3040 | X20 | Y22 | Y30 |
| Input Voltage | DC24V | |||
| Power Consumption | ≤2W(Customizable within 2W) | 1W | 0.72W | ≤1W(Customizable within 1W) |
| LEDs | SMD3535+SMD2835 | SMD2727/SMD3535 | SMD5050/SMD2727 | SMD5050/SMD2727 |
| Color | RGBW | RGB | RGBW | RGBW |
| Control Mode | DMX512 | DMX512/SPI | DMX512/SPI | DMX512 |
| Maximum serial number | 12PCS/m | 12PCS/m | 20PCS/m | 12PCS/m |
| Beam Angle(°) | 100 | 110 | 110 | 100 |
| CRI | ＞80 | |||
| IP Rating | IP66 | |||
| Working Temperature | −25°C ~ +50°C | |||
| Life Span | ≥50000h | |||
| Body Material | PC | |||
| Dimension | 40.0mm(L)x33.0mm(W)x 15mm (H） | 27mm(L)x19.9mm(W)x 11.5mm (H) | 25.3mm(L)x26.2mm(W)x 15.9mm (H) | 36.2mm(L)x32.5mm(W)x 13.6mm (H) |
Targeted Integration for Technical Professionals
The F3040 LED Point Light is engineered to meet the requirements of system integrators, lighting designers, and engineers focused on high-density pixel displays and architectural lighting installations. Providing pixel-perfect brightness and accurate color calibration, it is designed as a versatile solution from a leading led light supplier looking to serve complex urban landscape environments. Its modular array configurations—X20, Y22, and Y30—offer flexibility for installations in limited spaces without compromising uniformity. This product from a reputable led light factory supports scalable deployments with ease of maintenance, addressing the stringent demands of professional lighting projects.
Advanced Specifications for Performance Optimization
Featuring a durable PC housing rated IP66, the F3040 LED Point Light is built for outdoor resilience against dust and water ingress. It employs SMD3535 and SMD2835 LEDs delivering vibrant RGB and RGBW color options with a CRI above 80 for accurate color rendering. The device operates at DC24V with configurable power consumption ranging from 0.72W up to 2W per unit, optimizing energy efficiency without sacrificing luminosity. Compatible with DMX512 and SPI protocols, this led light solution enables precise digital control and seamless integration into existing systems. With wide beam angles of 100° to 110° and support for up to 20 units per meter, the unit ensures consistent light distribution across extensive installations.
Applications Across Outdoor and Architectural Environments
This LED point light is well-suited for outdoor pixel signage on commercial façades, dynamic event lighting, and architectural accent lighting for corporate buildings. Its precision control supports urban art installations, landmark illumination, and curved architectural surfaces. As part of led screen solutions, the F3040 supports digital wayfinding systems and high-density displays requiring reliable, energy-efficient lighting. Its robust design and flexible configuration allow deployment in diverse industry contexts including museums and retail storefronts, enhancing the visual impact while maintaining operational efficiency and compliance with rigorous environmental requirements.
Product Advantages
Structural and Design Strengths from Expert Manufacturers
The F3040 LED Point Light benefits from its modular construction, allowing customizable array configurations (X20, Y22, Y30) that integrate seamlessly into extensive led screen solutions. Its IP66-rated PC housing ensures robust protection for outdoor applications, while the connectorless snap-fit design enables quick assembly and simplified maintenance workflows. As a product offered by distinguished led screen manufacturers and led light suppliers, it supports scalable system integration efforts. This systematic architecture reduces installation complexity and enables consistent optical performance across varied deployment scenarios, minimizing downtime and installation costs.
Optimized Operational Performance and User Benefits
Performance-wise, this led light solution guarantees high color fidelity with CRI >80 along with energy-efficient operation at adjustable power levels from 0.72W to ≤2W. The compatibility with DMX512 and SPI control protocols offers advanced dynamic lighting capabilities and precise brightness adjustments tailored to user requirements. Its wide operating temperature range and long lifespan exceeding 50,000 hours translate into reliable, low-maintenance service for demanding outdoor environments. This leads to maximal uptime and ROI for lighting professionals sourcing from an experienced led light manufacturer recognized for efficient, durable lighting products.
Use Scenarios
Outdoor Architectural Façade Illumination
In the infrastructure and urban planning sectors, the F3040 LED Point Light functions as a critical element for accentuating building exteriors through energy-efficient, high-density pixel illumination. The IP66 rating guarantees durability against environmental factors while its flexible modular setup enables coverage of complex curved and planar surfaces. This led light solution integrates with DMX512-based control networks, supporting synchronized dynamic effects aligned with architectural design schemes. It allows lighting engineers to deliver precise color rendering and brightness uniformity, facilitating compliance with urban lighting standards and enhancing aesthetic value in demanding outdoor installations.
Dynamic Event and Digital Signage Environments
Within event management and commercial advertising domains, this point light serves as a reliable component for digital wayfinding, interactive signage, and large-scale pixel displays. Its robust build and connectorless snap-fit assembly speed up deployment during time-sensitive event setups. As part of led screen solutions provided by established led screen manufacturers, it ensures seamless control via DMX512 protocols for vivid color transitions and real-time effects control. The unit’s energy-efficient configuration supports long-duration operations under varying environmental conditions, aligning with performance standards expected by lighting designers and system integrators in high-visibility environments.
What materials are used in the F3040 LED Point Light to ensure its durability?
Our F3040 LED Point Light features a robust PC housing rated IP66, offering excellent protection against dust and water. It uses high-quality SMD3535 and SMD2835 LEDs to maintain brightness and color accuracy in outdoor environments, making it a reliable choice among led light manufacturers for professional installations.
Can you customize the power consumption and color options of the F3040 LED Point Light?
Yes, we offer configurable power levels from 0.72W up to ≤2W to fit project efficiency needs. Color options include RGB and RGBW variants, enabling flexible, vivid lighting effects. This level of customization reflects our commitment as a trusted led light supplier to deliver tailored LED solutions.
How does the connectorless snap-fit design benefit installation and maintenance?
Our snap-fit design allows quick assembly without connectors, significantly reducing labor time and simplifying maintenance. This is ideal for complex or tight outdoor installations, ensuring efficient deployment and long-term reliability in both small and large-scale LED projects.
What control protocols does the F3040 support for professional lighting systems?
The F3040 supports DMX512 and optional SPI/Art-Net protocols for precise pixel-level control in dynamic lighting setups. These protocols allow lighting designers and engineers to integrate our product seamlessly into existing systems, ensuring high-performance color and brightness management.
